Flywoo Explorer LR V2.2 4" Quadcopter Analog W/ Caddx Ratel 2

The Flywoo Explorer LR V2.2 Analog is a brand new type of quad known as “#MicroLongRange”  which was created by Dave_C FPV in collaboration with Flywoo. This masterpiece will push your fpv skills to the max! The Explorer LR V2.2 HD comes with a Caddx Ratel 2 camera, Atomic 5.8GHz RHCP antenna,  GOKU GN405 V1.3 16×16 Stack, NIN 1404 V2 2750KV Motors, V2.0 GPS… making this Sub250 4″ quad a winner!

V2.2 CHANGELOG

• HM850 850mw VTX & AGC Microphone module
• Upgraded GOKU GN405 V1.3 Stack
• Caddx Ratel 2 Camera
• Upgraded V2.0 GPS

Note: Choose a receiver: PNP, ELRS, FrSky XM+, or TBS Crossfire.

Note:  Action Camera is NOT Included.

VIDEO: This BNF 4″ Long Range Drone Flies for 18 minutes!

• V2.0 GPS which uses copper foil to effectively prevent the Vista signal interference
• Strongly recommended for FPV beginners and pilots who like to cruise!
• Built-in Bluetooth module
• GOKU GN405 V1.3 Stack
• Caddx Ratel 2 Camera
• Sub250 Quad

GOKU GN405 NANO STACK

This is another powerful stack from Flywoo. The GOKU G405 Nano flight controller is packed with features including a barometer, 16MB BlackBox, 6 complete hardware serial ports, I2C functionality, and WS2812 LEDs on each corner.

NON-SLIP UPGRADE

High-Quality sticky battery pad for your LiPo Batteries. These durable battery pads are made from PU material and can stick to a battery at 90° on its side and even rotate 180° without falling!

PRE-TUNED AND PRE-SETUP

This RTF is fully built and tested by build technicians at Flywoo.

• VTX: GOKU HM850 5.8Ghz U.FL 850mw VTX w/ AGC Microphone
• Antenna: Atomic 5.8GHz Antenna Length 130mm (U.FL RHCP)
• FC & ESC : GOKU GN405 Nano 13A 16×16 Stack
• Frame: Explorer LR 4” Frame Kit V2 Analog
• Camera: Caddx Ratel 2 120TVL 1.8mm
• Propellers: Gemfan 4024 2-Blade
• Weight (without battery): 162.8g
• Motors: NIN 1404 V2 2750KV
• GPS: Flywoo GM8 Mini V2.0
• Wheelbase: 168mm

IMPORTANT NOTES

• The DJI Remote Controller is recommended for beginners but NOT required to use the FPV System, since you won’t need to set up another receiver. If you don’t have the DJI Remote Controller, you will need a receiver for your transmitter. and then bind to your own radio as usual.
• If you do not have the frsky transmitter, please downgrade the version lower than 2.X.X, www.frsky-rc.com for more details.
• Our current frsky receivers default version in 2.XX, requires us to use of the same version of frsky transmitter.

• Tattu Explorer 1050 4S XT30 Battery
• Explorer 18650 3000mah Battery
• 4S 1300 120C XT30 Battery
• 4S 650 95C XT30 Battery
• 4S 750 95C XT30 Battery
• 4S 850 95C XT30 Battery

•   (Insert links such as manuals, firmware, etc)

• 1x Flywoo Explorer LR V2.2 4″ Quadcopter Analog w/ Caddx Ratel 2 (Pre-Built and Tested)
• 2x Gemfan Hurricane 4024 20 Blade Propellers (Set of 4)
• 1x Side Carbon Plate (Set of 2)
• 1x Atomic Antenna
• 1x 3D Printed Part
• 1x Hardware Set
• 1x Battery Pad
• 1x Lens Cover
• 1x LiPo Strap
