Lumenier TinyFISH Power Stack F3 16x16mm Flight Controller + 4A 4-in-1 ESC + FrSky Rx

The Lumenier tinyFISH Power Stack combines both a F3 Flight Controller and 4A 4-in-1 ESC into a compact stack. It uses a powerful F3 processor along with top of the line hardware. Now you can get all the performance from an F3 based flight controller in a truly micro size! This flight controller uses 16x16mm mounting holes and a low profile design allowing for smaller airframe designs than ever before. The tinyFISH comes with BetaFlight pre-installed.

The tinyFISH F3 Flight Controller has a built 8CH SBUS FrSky compatible receiver, making setup a breeze. This Power Stack has been designed by and named after our friends at fishpepper.de under an open source license.

4-in-1 ESC

Features

• 16x16mm M2 hole-to-hole spacing (20x20mm outer dimension)
• a total weight of 1.2g (!)
• BLHeli_S
• DSHOT600 (rev 0.5 and higher)
• regenerative breaking
• 4.3A continuous current
• openhardware + opensource software

Please note that this board is for 1S operation only. Do not even try 2S, the board will be immediately releasing all it’s magic smoke and stop working…

Specifications

• Input: 1s Lipo
• Constant: 4.3 Amps
• Burst: 5 Amps
• Weight: 1.3g
• Dimensions: 21x21x2mm
• Mounting Dimensions: 16x16mm
• Motor wire: 70mm
• Signal wire: 140mm
• MCU: BusyBee2 MCU at 48MHz
• PCB – 4 Layer Blind Pole PCB – 3oz Pour
• Mosfet: N-Channel
• BEC: OPTO (none)
• Supports Damped mode, Oneshot125 and Multishot. DSHOT

Flight Controller

Software/Hardware Features

• 1-3S Direct Lipo input support (3-12v) (LiPo power is required for PC connectivity!)
• 16x16mm hole to hole spacing (20x20mm outer dimension)
• Integrated FrSky compatible SBUS receiver (basically an integrated uSKY rx)
• STM32F3 CPU
• MPU-6000 SPI gyro
• Supports DSHOT
• Integrated Blackbox dataflash
• Integrated voltage- and current-sensor
• Buzzer output
• RGB led output
• Open hardware

Specifications

• CPU: STM32F3
• SPI: ICM-20608-G Accelerometers and Gyroscope
• Mounting Hole: 16x16mm, M2
• Can support current, voltage monitoring
• 2.4G Receiver
• Channel: 8CH
• SUBS Output
• Control Range: 200m
• Compatible with Frsky X9D Plus Transmitter

Includes

• 1x Lumenier tinyFISH F3 Flight Controller
• 1x Lumenier tinyPEPPER AA 4-in-1 ESC
• 1x Set of nylon spacers, screws, nuts

Downloads

• Download Betaflight Configurator – Latest Betaflight Firmware
