NewBeeDrone AcroBee65 V4 BNF W/ BeeBrain BLV4 – ELRS 2.4GHz

The NewBeeDrone AcroBee65 V4 BNF features a BeeBrain BLV4 AIO flight controller with a built-in VTX and ELRS receiver. The Flow 0802 27000KV motors make this whoop really zip around!

VIDEO: NewBeeDrone AcroBee65 BLv4 ELRS BNF | New Product Release

• NewBeeDrone BeeBrain V4 AIO
• Flow 0802 27000KV Motors
• Built-in ELRS Reciever
• 65mm Wheelbase

• AIO Flight Controller: BeeBrain BLV4 ELRS with built-in VTX and Crossfire Receiver
• Motors: Flow 0802 27000kv Double Ball Bearing Brushless motor
• Propeller: Azi Tri-Blade 31mm 1.0 Propeller (Clear Purple)
• Frame: Cockroach65 Brushless Frame (Clear Purple)
• Total Weight of the Drone without battery: 24.8g
• Canopy: Goober Canopy (Clear Purple)
• Camera: BeeEye Camera
• Drone Size: 65mm

BEEBRAIN V4 AIO

• Receiver: ELRS2.4 Diversity receiver(ESP32 compatible with wifi&bluetooth firmware update) 2.4G T-Antenna(Top) & normal 2.4G antenna(bottom)
• VTX: Switchable output power from 5mw- 25mw(for Racing) – SmartMAX(SmartMax up to 400mw)  with BeeTX 5.8Ghz Antenna
• Battery input: 1-2S (Preset only support 1S, 2S will need throttle cap at less 50%)
• Flight Controller Weight: 6.5g(Include antennas and battery connector)
• ESC: 12A BLHeliS Pre-Flash with Bluejay 0.16 target: S-H-40 48kHz
• OSD: NBD7456 Graphical OSD compatible with Betaflight OSD
• Flight Controller Size: Outer dimensions: 29x29x7.6mm
• Uart2: Tx&Rx for ExpressLRS2.4G Receiver
• Power Connector: NBD-PH2.0 connector
• Flight Controller: BeeBrain BLv4 ELRS
• Flight Controller Holes: 25.5×25.5mm
• ESC Connector: JST-1.0 3Pin
• Uart1:  Tx&Rx free
• MCU: STM32F411

IMPORTANT NOTES

• The 27000kv motor on your device is designed for high performance and may be too strong for most users. To ensure safety, the factory has set the device to only use 80% of the maximum power by default. However, if you require more power, it is possible to adjust the settings through the Betaflight software, which can be accessed under the PID tab. Please note that increasing the power beyond the default setting may increase the risk of damage to the device or injury to yourself or others, and should be done with caution.
• Binding process: Power up the drone 3 times, on the third time you plug in power, and the ELRS Receiver will get into the binding mode.

• Battery: 1-2S (PH2.0 connector)

• BeeBrain BLV4 ELRS3.0 receiver firmware
• BeeBrain BLV4 ELRS2.0 receiver firmware

• 1x NewBeeDrone AcroBee65 V4 BNF w/ BeeBrain BLV4 – ELRS 2.4GHz
