QAV-SKITZO Dark Matter RTF W/ FrSky RX

This is the QAV-SKITZO Dark Matter RTF w/ FrSky. Fully built, tuned and ready to fly out of the box. Simply add your own radio, bind the included receiver and go fly! This QAV-SKITZO RTF features premium components like the Lumenier MX2206-9 2450KV Motors, RunCam Eagle 2 Pro Lumenier Edition Camera, TX5GS VTX, Lumenier AXII antenna, and RaceFlight FC and ESC. This is the Skitzo approved setup and it flies beautifully.

About the Airframe

The Lumenier QAV-SKITZO Dark Matter FPV Freestyle quadcopter is a symmetrical X, ultra-durable, finely tuned airframe designed for high performance FPV Freestyle flying. The QAV-SKITZO was created in collaboration with and named after the flow master himself SKITZO FPV. This freestyle airframe has been designed from the ground up to withstand the rigors of freestyle flying pilots like Skitzo put their airframes through.

The QAV-SKITZO features premium Lumenier carbon fiber with a beautifully finished chamfered edge, giving the quad a sleek look while also improving the durability by removing hard edges. Each plate is sealed with a layer of clear coat paint further strengthening each piece and giving it an awesome finished look. No rough edges or carbon dust to worry about, and no sanding required.

This RTF has been fully built and test flown for you, so you can simply bind your radio and go! Our professional build team takes the guess work out of building and tuning for you by pre-programming the flight controller settings and using only high quality Lumenier motors, ESCs and FPV gear.

Features

• This RTF version is fully built, test flown and comes with everything to get you going. Just bind the receiver and setup your radio and you’re good to go.
• Pre-tuned with SKITZO’s custom settings in RaceFlight!
• Full 3K Carbon Fiber airframe with removable 4mm arms.
• Ultra durable 3mm top and bottom plates
• Custom Skitzo decal sticker sheet
• Compact size for 5″ propellers, 214mm motor to motor.
• Black Oxide steel screws
• Easy grip purple anodized spacers
• “Bumpers” on the end of the arms to protect the motor during a crash
• Lightweight and rigid

Weight

• Airframe: 96g (airframe + hardware), 100g (with sticker decal).
• AUW: The QAV-SKITZO Dark Matter FPV Quadcopter is flown with an AUW of 315g (excluding battery)

RTF Included Components and Parts

• A fully built and tested Lumenier QAV-SKITZO Dark Matter FPV Quadcopter
• 1x Lumenier Indestructible Kevlar Lipo Strap – 16x250mm
• 1x RunCam Eagle 2 Pro CM-1200 Lumenier Edition (White) SKU: 7849
• 2x Lumenier 5x5x3 – Butter Cutter Propeller (Set of 4 – SKITZO Teal)
• 1x Lumenier TX5GS 25-200-500mW 5.8GHz FPV Transmitter w/ BFCMS Control (MMCX)
• 4x Lumenier MX2206-9 2450KV Motors
• 1x RaceFlight Skitzo Black Bolt 30A 4-in-1 V2 ESC
• 1x RaceFlight SKITZO RevoltOSD Flight Controller
• 1x Lumenier AXII MMCX 5.8GHz Antenna (RHCP)
• 1x FrSky R-XSR 2.4GHz 16CH ACCST Micro Receiver w/ S-Bus & CPPM

Additional Suggested Parts (not included in the RTF)

• Lipo: Lumenier 1300mAh 3s (beginner) or Lumenier 1300mAh 4s (advanced)
• RC TX/RX: FrSky Taranis Q X7 2.4GHz 16CH Transmitter (Black)
• FPV Goggles: Fat Shark Dominator V3 FPV Goggles (Combo Kit)
• HD Recording Camera: GoPro Hero5 Session

Videos
